Port Select:

Click the Select button to quick-select the corresponding port
based on the port number you entered.

Select:

Select the desired port for Storm Control configuration. It is
multi-optional.

Port:

Displays the port number of the switch.

Broadcast:

Select Enable/Disable to enable/disable the broadcast control
function for the port.

Multicast:

Select Enable/Disable to enable/disable the multicast control
function for the port.

UL-Frame:

Select Enable/Disable to enable/disable the UL-Frame control
function for the port.

Rate(bps):

Select the bandwidth for receiving broadcast packets,multicast
packets and UL-Frame on the port. The packet traffic exceeding
the bandwidth will be discarded.

LAG:

Displays the LAG number which the port belongs to.

Note:

If you enable storm control feature for the ingress rate limit-enabled port, ingress rate limit feature
will be disabled for this port.
