9
1/4 HP
130 VDC
2500 RPM
1.80 ADC
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
CURR. LIMIT IR COMP
1/8 HP
90 VDC
1750 RPM
1.30 ADC
1/8 HP
130 VDC
2500 RPM
1.00 ADC 1/10 HP
90 VDC
1725 RPM
1.10 ADC
1/12 HP
130 VDC
2500 RPM
0.71 ADC 1/20 HP
90 VDC
1750 RPM
0.56 ADC
1/2 HP
240 VDC
2500 RPM
1.80 ADC 1/4 HP
180 VDC
1750 RPM
0.56 ADC
1/4 HP
240 VDC
2500 RPM
1.00 ADC 1/5 HP
180 VDC
1725 RPM
1.10 ADC
1/6 HP
240 VDC
2500 RPM
0.71 ADC 1/8 HP
180 VDC
1750 RPM
0.56 ADC
115 VAC INPUT
240 VAC INPUT
Figure 4. Typical CURR. LIMIT & IR COMP Settings
