sure to use the zip ties, this is a very important step that should not be skipped. Once this step is complete and the
lighting strips and wires are secure, allow ample time for the adhesive to settle and cure.
6.
Find a secure and dry place to mount the control box. We recommend mounting it under the seat or in a water tight
compartment if possible. If this is not possible then we suggest mounting the control box in the driest location
available.
7.
Connect the red power wire from the control box to the positive terminal of the battery. If the power wire needs to be
extended, be sure to use 16 or 18 gauge automotive grade wiring. Be sure to reinstall the fuse within 6 inches of the
battery. Connect the black ground wire to the negative terminal of the battery.
8.
The kit was designed using a modular locking plug system for connecting the lighting strips to the control box by using
the included wire harness. Start plugging the male connections from the strips and control box into the female
connections of the harness.
9.
Test the functionality of the kit once more. If everything seems to be working properly, you can now reinstall any trim
you removed for the installation.
10. For more information, please refer to our instructional videos that can be found a
Wireless Remote Functions:
This kit provides multiple lighting patterns and several brightness levels, which are easily operated by using the
included wireless remote. The wireless remote features four buttons, “A, B, C, D”
Button A: Cycles through 15 solid colors, as well as a color cycle and color fade pattern.
Hold for 5 seconds to select brightness level when on a solid color.
Button B: Activates the strobing pattern when a single color is selected.
Hold to increase pattern speed when on a color cycle/color fade pattern.
Button C: Activates fading pattern when a single color is selected.
Hold to decrease pattern speed when on color cycle/color fade pattern.
Button D: Power On/Off
For accessories, add-on kits, replacement parts and/or Technical Support, please visit
or more information.
