Apollo CNX80 Pilot’s Guide
44
Initiating Manual Track Using Manual Track,
Speed, and Altitude
Simulator mode only.
Steep Turn Ahead (or others) Pilot awareness.
Arrival (or) Arrival in x sec Pilot awareness.
Pilot Nav (or) Pilot Nav in x sec Pilot awareness.
DISCONTINUITY Ahead Modify flight plan or perform Direct-To function.
DISCONTINUITY Modify flight plan or perform Direct-To function to
reestablish navigation.
Hold (Parallel, Teardrop, or Direct) Pilot awareness.
Excessive Heat, Possible loss of cooling CNX may fail or behave erratically.
WARNING Loss of Integrity Cross-Check NAV GPS position integrity lost. Verify by cross-check-
ing with VHF Nav.
Integrity Restored Normal Ops Pilot awareness.
WARNING Loss of Navigation (Insufficient
Sats, Position Error, Loss of GPS Com)
GPS position lost. Use other Nav equipment.
Configuration Failure: Unit needs servicing Do not use for IFR ops or primary navigation. Con-
tact dealer or Customer Service.
Configuration Corrupt: Use Ground Maint
Mode to correct
Checked on power-up. System configuration
invalid. See dealer or call Customer Service.
Configuration Error: Verify User Settings Go to System Configuration page and check user
settings.
CDI Selection Should be set To (Localizer,
ILS, or VOR)
Pilot awareness.
VOR Receiver Should Be Tuned To xxx.xx For
(name of approach)
Pilot awareness.
Database Invalid: Database needs updating Database unavailable until updated.
Database Invalid: Software needs updating Database unavailable until unit software is
updated.
Database Expired on (date) Database should be updated.
Altimeter correction failed switching to alter-
nate correction mode
Altimeter corrections failed. Unit will prompt for
other inputs.
Flight Plan Mismatch with Database Invalid
Waypoints Found
Flight plan waypoints are no longer in the Nav
database.
Baro Correction xx.yy CRSR to Change,
ENTER to Accept
Input correct baro setting.
Warning Loss of Navigation LOI On
Approach
Execute missed approach using other nav equip-
ment.
Message Description
Messages
