Apollo CNX80 Pilot’s Guide

23

5. Turn the Large knob to move to the Type selection. Turn the Small

knob to choose between Differential, Ground, or Air. Differential
means the value was referenced to another calibrated source or
unit. Ground means the unit was calibrated while on the ground. Air
means the unit was calibrated while in the air.

6. Turn the Large knob to move to the Location selection. Press the

Cursor knob in to start editing. Turn the Small knob to change the
character. Turn the Large knob to the next character and turn the
Small knob to change the character. When editing is complete,
press the Cursor knob again to exit editing the Location.

7. Turn the Large knob to move to the Brg Error selection. Turn the

Small knob the change the value required to center the needle. Left
for “-” and right for “+” corrections.

8. Turn the Large knob to move to the Name selection. This value if for

recording the name of the person entering the values in the Test
Log. Press the Cursor knob in to start editing. Turn the Small knob
to change the character. Turn the Large knob to the next character
and turn the Small knob to change the character. When editing is
complete, press the Cursor knob again to exit editing the Name.
