APC SURGEARREST PMF3DS-A - Manual (Page 14)

8220-0014-06
Customer Connections 320 kA - 480 kA
Ø C Ø A N
Customer Connections 120 kA - 240 kA
Ø C
Ø A BØ
N
WIRING DIAGRAMS WITH INTEGRAL DISCONNECT
Chasis Ground
Chasis Ground
Figure 5: Single-phase, 3-Wire, Grounded Installation with Integral Disconnect
AØ CØ N
Customer Connections 120 kA - 240 kA
Figure 6: Single-Phase, 3-Wire, Grounded Installation with Integral
Disconnect
Customer Connections 320 kA - 480 kA
AØ
CØ
N
Ø C Ø A BØ N
Customer Connections 120 kA - 240 kA
Figure 6: Three-phase, 3 or 4-Wire, Grounded Wye Installation with Integral Disconnect
NOTE: The neutral conductor is not present on 3-wire, grounded neutral power systems.
For these systems tie the neutral and ground lugs together.
WIRING APC MODULAR PANEL PRODUCTS Surge Protective Device (SPD)
