Jackco Power Post Model 892 - Manual (Page 7)

PARTS LIST
Please refer to the Parts drawing when ordering parts. Not all components are replacement items, but
are illustrated as a convenient reference of location and position in the assembly sequence. When
ordering parts, please give model no., and description below. Call or write for current pricing: Jackco
Transnational Inc. South El Monte, CA 91733 TEL: (626)582-8055 or visit us at www.jackco.com
Part # Description Qty
01 Frame 1
02 10 Ton Ram 1
03 Wheel 2
04 Hex Head Screw (3/8” x 2- 9/16”) 2
05 Hex Head Nut (3/8) 2
08 Lock Plate 1
09 Stop Plate 1
10 Spring 1
11 Chain 1
12 Inner Hex Screw (3/16 x ¾”) 2
13 Lever Arm 1
14 Swivel Castor 1
15 Pin 2
16 Snap Ring “C” 4
17 Female Adapter (Snap) 1
18 male Adapter (Snap) 1
19 Spindle 4
20 Secondary Anchor 1
21 Chain Pulley 1
22 Spring Hair Pin Clip 4
Replacement Parts Illustration for Model 892
6
