MIXING AMPLIFIER
28 PMU-360N/480N/600N
PMU-360N PMU-480N PMU-600N
Rated Output Power 360W 480W 600W
Frequency Response (SP OUT/1W output) 80Hz~15kHz
T.H.D (Rated Output, 1kHz) Less than 0.5%
S/N (Rated Output) More than 78dB
Tone Control (100Hz, 10kHz) ±10dB
Input Sensitivity/ Input 1~5 MIC -50dBu/2kΩ
Impedance
LINE -10dBu/2kΩ
Input 6 -10dBu/10kΩ
TEL IN 0dBu/10kΩ
EXT IN 0dBu/20kΩ
MIX Out/Impedance 0dBu/10kΩ
Speaker Output Level/Impedance LOW-Z 54V/8Ω 62V/8Ω 70V/8Ω
HIGH-Z
100V/28Ω 100V/21Ω 100V/16Ω
70V/14Ω 70V/11Ω 70V/8Ω
Operation Temperature -10°C ~ +40°C
Power Source 100-120VAC or 220-240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption (1/8W output) 80W 100W 160W
Weight (SET) 5.2kg/11.5lb
Dimensions (SET) 420(W)x88(H)x319(D)mm/16.5(W)x3.5(H)x12.6(D)in
* Design and specification are subject to be changed for the improvement of product quality without pre notice.
