PROGRAM DISTRIBUTOR
4 PO-6106
Front Panel Front Panel
1. INPUT PEAK INDICATOR
This LED lights to indicate the input level is too high.
2. OUTPUT INDICATORS
These LEDs indicate signal on their associated outputs.
3. POWER INDICATOR
When the unit is on, this power indicator LED is lit.
4. INPUT LEVEL CONTROL
This knob provides continuous control of the input level.
5. OUTPUT LEVEL CONTROL
This knob provides continuous control of the output level for each of the six outputs.
6. POWER SWITCH
This switch is used to turn the unit ON/OFF.
