31
LP-200 REV. 3.25.14
Figure 13 – SE Model Parts Breakdown – LP-200-E
Item No SSC-50SE SSC-80SE / 119SE Description QTY.
1 6075P-002 6075P-008 HOT WATER OUTLET 1
2 6075P-003 6075P-009 HOT WATER DIP TUBE 1
3 6075P-044 6075P-044 ANODE ROD, STANDARD SOLID 1
4 6075P-054 6075P-054 GASKET - ELECTRIC ELEMENT 1
5 6075P-052 6075P-052 ELECTRIC ELEMENT (W/GASKET) 1
6 6060P-1008 6060P-1008 UPPER THERMOSTAT CONTROL 1
7 6060P-633 6060P-633 THERMODISC MOUNTING CLIP 1
8 6060P-632 6060P-632 5/16-18 HEX NUT - THERMODISC MOUNTING CLIP 2
9 6060P-994 6060P-994 PLASTIC PROTECTIVE COVER 1
10 6060P-187 6060P-187 ELECTRICAL BOX COVER 2
11 6075P-006 6075P-006 #8 X 3/4" SELF TAPPING SCREW 2
12 N/A N/A SOLAR PANEL SURFACE MOUNTED SENSOR 1
13 6075P-053 6075P-053 KAMCO FIBERGLASS INSULATION 1
14 TP1000 TP1000 3/4" RELIEF VALVE 1
15 SN1002 SN1002 DRAIN VALVE 1
16 N/A 6060P-631 1-3/4" HOLE FLANGE 1
Table 5 – SE Model Replacement Parts List
