STRIDER ESSENTIAL SERIES
SPECIFICATION
SilverStone Strider Essential
ST50F-ES230
ATX12V Switching Power Supply
With Active PFC
PS/2
01
1.1 Scope
This specification defines the performance characteristics of a single phase 500 watts,
5 output power supply. This specification also defines worldwide safety and
electromagnetic compatibility requirements for the power supply which is intended for
use in computer products.
1.General
2.1 Input Voltage
Nominal Voltage Voltage Variation Range
230 Vrms 207 - 253 Vrms
2.Input Characteristics
2.2 Input Frequency
Nominal Frequency Frequency Variation Range
50 Hz 47 Hz to 63 Hz
* The power supply must operate at above frequency with 207 - 253VACrms input voltage range.
02
Output Voltage Load MIN Range MAX Regulation Ripple P-P Max.
Maximum continuous total DC output power should not exceed 500W.
Maximum continuous combined load on +3.3VDC and +5VDC outputs shall not
exceed 120W.
NOTE:
Noise test should be measured with 20 MHz bandwidth frequency oscilloscope.
The output terminal shall add a tantalum capacitor of 10uF in parallel with a ceramic
capacitor of 0.1uF.
1. +5V
2. +3.3V
3. +12V
5. -12Vs
6. +5V
0.2A
0.1A
0.1A
0.0A
0.0A
20.0A
24.0A
34.0A
0.3A
2.5A
±5%
±5%
±5%
±10%
±5%
120mV
120mV
200mV
200mV
100mV
2.3 Max. Input AC Current
Max. Input Current Measuring Range
4.0A 207-253 Vrms
2.4 Inrush Current
The power supply must meet inrush requirements for any rated AC voltage, during
turn on at any phase of AC voltage, during a single cycle AC dropout condition,
during repetitive ON/OFF cycling of AC, and over the specified temperature range.
The peak inrush current shall be less than the ratings of its critical components
(including input fuse, bulk rectifiers, and surge limiting device).
2.5 Efficiency
SST-ST50F-ES230 provides an efficiency of >80% when measured at full load
under 230V/50Hz condition.
3.1 Normal Operation Output
3.Output characteristics
