ST50NF

5-1. UL 60950-1, 2005 (2nd Edition.)

5-2. BSMI (CNS14336: 94)

5-3. TUV EN 60950-1: 2006+A11

5-4. CB

5. Safety

6-1. CE

6-2. BSMI (CNS13438: 95)

6-3. FCC Part 15 Subpart B, Class B at system load

6-4. CISPR 22 AS/NZS CISPR 22: 2006, CLASS B

6. EMI Requirements

The power supply shall withstand for 3 seconds without breakdown the application of an 1800Vac-supply

voltage applied between both input line and chassis (10ma AC Cutoff current). Isolating transformers shall

similarly withstand 4242Vdc applied between both primary and secondary windings for a minimum of one

minute.

7. Dielectric Voltage Withstand (HI-POT)

Active Power Factor Correction, complies with EN 61000-3-2: 1995 + A1 + A2: 1998, Class D.

8. PFC

Comply with IEC 61000-4-2.

9. Electrostatic Discharge (ESD)

Comply with IEC 61000-4-4.

10. EFT/ Burst

Comply with IEC 61000-4-5.

11. Surge

Applying 115 Vac

±

10 % or 230 Vac

±

10% input voltage and maximum load (60%)

for this product in 45

±

5 C chamber.

12. Burn-In

The power supply shall have a minimum mean time between failure greater than

80,000 hours Minimum (Without Cooling Fan) at continuous operation of 100%

load and an ambient temperature of 25 C.

13. M.T.B.F.

07

o

o

08

There are two leds for the monitoring the status of the power supply,which allows

users to perceiveA full awareness of the working condition of the power supply.

The temperature LED indicates surface temperature of the power supply’s housing cage.

14. LED Indicators

Dimension (W x H x D): 150mm (5.90”) x 86mm (3.38”) x 160mm (6.29”)

15.1. Physical Dimension

M/B 24PIN connector

15. MECHANICAL REQUIREMENTS

The Status-LED indicates power

supply’s working.

Caution: DO NOT TOUCH THE SURFACE OF POWER SUPPLY WHEN

THE TEMP-LED INDICATES RED, IT MIGHT BE DANGEROUS.

Temp. Status

High 55 C

Low 55 C

LED Color

Red

Green

o

o

>

=

>

Orange

Blue

Black

Green

Black

Black

Black

White

Red

Red

Red

Black

Signal

+3.3V

-12VDC

COM

PS-ON

COM

COM

COM

N/C

+5VDC

+5VDC

+5VDC

COM

Pin

13

14

15

16

17

18

19

20

21

22

23

24

Pin

1

2

3

4

5

6

7

8

9

10

11

12

Signal

+3.3V

+3.3V

COM

+5VDC

COM

+5VDC

COM

PWRGOOD

+5Vsb

+12V

+12V

+3.3V

Orange

Orange

Black

Red

Black

Red

Black

Grey

Purple

Yellow

Yellow

Orange

Power Status

Standby

Power ON

Power Fault

LED Color

Amber

Green

Red
