7. MECHANICAL REQUIREMENTS
7.1 Physical Dimension
7.2 Connectors
M/B 24PIN connector
125 mm (W) × 63.5 mm (H) × 100mm (D)
Signal Pin Pin Signal
Orange +3.3V
Orange +3.3Vsense
Blue -12VDC
Black COM
Green PS-ON
Black COM
Black COM
Black COM
White N/C
Red +5VDC
Red +5VDC
Red +5Vsense
Red +5VDC
Black COM
1 +3.3V
2 +3.3V
3 COM
4 +5VDC
5 COM
6 +5VDC
7 COM
8 PWRGOOD
9 5Vsb
10 +12V
11 +12V
12 +3.3V
Orange
Orange
Black
Red
Black
Red
Black
Grey
Purple
Yellow
Yellow
Orange
13
13
14
15
16
17
18
19
20
21
22
22
23
24
6.6. INSULATION RESISTANCE
Primary to Frame Ground : 20 Meg.ohms Minimum
Primary to Secondary : 20 Meg.ohms Minimum
08
ATX 12V 4PIN (4+4PIN EPS 12V in split mode)
Signal Pin Pin Signal
Black GND
Black GND
1
2
3 +12V Yellow
4 +12V Yellow
SATA connector
Signal Pin
Orange +3.3V
Black COM
Red +5V
Black COM
Yellow +12V
5
4
3
2
1
4PIN peripheral connector (HDD) 4PIN floppy connector (FDD)
Signal Pin Pin Signal
Yellow +12V
Black COM
Black COM
Red +5VDC
1
2
3
4
1 +5VDC
2 COM
3 COM
4 +12V
Red
Black
Black
Yellow
EPS 12V 8PIN connector
Signal Pin Pin Signal
Yellow +12V
Yellow +12V
Yellow +12V
Yellow +12V
5
6
7
8
1 COM Black
2 COM Black
3 COM Black
4 COM Black
SFX Form Factor
