7
7. LABELLING
Label marking will be permanent, legible and complied with all agency requirements.
7.1. MODEL NUMBER LABEL
Labels will be affixed to the sides of the power supply showing the following:
- Manufacturer’s name and logo.
- Model no., serial no., revision level, location of manufacturer.
- The total power output and the maximum load for each output.
- AC input rating.
8.0. MECHANICAL SPECIFICATIONS
8.1 Physical Dimension
125 mm (W) × 63.5 mm (H) × 100 mm (D)
8.2 Connectors Define
ATX 12V 4PIN(4+4PIN EPS 12V in split mode)
Signal Pin Pin Signal
Orange
Orange
Blue
Black
Green
Black
Black
Black
White
Red
Red
Red
Red
Black
+3.3V
+3.3Vsense
-12VDC
COM
PS-ON
COM
COM
COM
N/C
+5VDC
+5VDC
+5Vsense
+5VDC
COM
13
13
14
15
16
17
18
19
20
21
22
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
+3.3V
+3.3V
COM
+5VDC
COM
+5VDC
COM
PWRGOOD
+5Vsb
+12V1
+12V1
+3.3V
Orange
Orange
Black
Red
Black
Red
Black
Grey
Purple
Yellow
Yellow
Orange
Signal Pin Pin Signal
Black
Black
GND
GND
1
2
3
4
+12V1
+12V1
Yellow
Yellow
