4.0. OUTPUT ELECTRICAL REQUIREMENTS
4.1 OUTPUT VOLTAGE AND CURRENT RATING
Output
MINIMUM
LOAD
NORMAL
LOAD
MAXIMUM
LOAD
PEAK
LOAD
LOAD
REG
LINE
REG.
RIPPLE
& NOISE
+3.3V 0.5A ˄˃˔ 20A ̈́5% ̈́1% 70mV P-P
+5V 0.5A ˄˄˔ 22A ̈́5% ̈́1% 70mV P-P
+12V1DC 1.0A ˊ˔ʳ 14A ̈́5% ̈́1% 140mV P-P
+12V2DC 1.0A ˋ˔ 16A 19A ̈́5% ̈́1% 140mV P-P
-12V 0.0A ˃ˁ˅ˈ˔ 0.5A ̈́10% ̈́1% 140mV P-P
+5VSB 0.0A ˄ˁ˅ˈ˔ 2.5A 2.5A ̈́5% ̈́1% 70mV P-P
( 1 ) +3.3V & 5V total output not exceed 125W.
( 2 )Total output continuous shall not exceed 300W watts.
( 3 )+12V Peak current is 19A(less then 10m Sec.),minimum voltage during peak is >10.8Vdc.
( 4 )5Vsb Peak current is 3A(less then 500m Sec.), minimum voltage during peak is > 4.5Vdc.
( 5 )maximum combined current for the 12V outputs shall be 22A.
Voltages and ripple are measured at the load side of mating connectors with a 0.1 uF monolithic
ceramic capacitor paralleled by a 10 uF electrolytic capacitor across the measuring terminals.
4.2. LOAD CAPACITY SPECIFICATIONS
The cross regulation defined as follows, the voltage regulation limits DC include DC Output
ripple & noise.
LOAD +3.3V +5V +12V1 DC +12V2 DC -12V +5VSB
4.3. HOLD-UP TIME (@FULL LOAD)
115V / 60Hz : 17 mSec. Minimum.
230V / 50Hz : 17mSec. Minimum.
The output voltage will remain within specification, in the event that the input power is removed or
interrupted, for the duration of one cycle of the input frequency. The interruption may occur at any
point in the AC voltage cycle. The power good signal shall remain high during this test.
19A
-
-
-
Condition_1
Condition_2
Condition_3
Condition_4
Condition_5
Condition_6
Condition_7
Condition_8
Condition_9
X
0.5A
0.5A
0.5A
1A
1A
4.54A
18A
20A
X
0.5A
0.5A
15A
2A
14A
22A
2A
11.8A
X
1A
1A
1A
14A
2A
6.72A
1A
6.72A
X
1A
1A
16A
1A
2A
6.72A
1A
6.72A
X
0A
0.5A
0.1A
0.1A
0.1A
0.3A
0A
0.3A
2.5A
0A
0A
0.1A
0.1A
0.1A
2A
0.1A
2A
