The information in this manual furnished for information use only, is subject to change without notice, is not to be
construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
©2004 ATN Corp. All right reserved.
2
Battery installation
APPLICATION
Our new Aries 390 “Paladin” is the best 1 st
generation scope on the market.
We started by improving the optical configu-
rations with lowered F-stop factors (from 1.7
on previous models to 1.4(!) on new) and
optical resolution that is beyond current
military standards (old 45lp/mm and the
new is 60lp/mm). This provides you with the
brightest and clearest image in a 1 st gen unit.
Then we added our precision “red on green”
aiming system, easy push button operation,
reticle brightness adjustment and our new
detachable, most powerful in the industry
450mw Infrared Illuminator with dedicated
windage and elevation adjustments.
Do you want the best NVD weapon sight
on the market? If so then our new Aries
6900/7900/8900 “Crusader” is for you.
It doesn’t get any better then the Crusader
when it comes to performance. For the Cru-
sader we use a top of the line “Prime Select”
light intensifier tube for added light gain and
resolution. Combine this select tube with 5x
magnification and a super fast F:1.4 lens the
image that you will get out of your Crusader
is unbelievable.
The best optics, tubes and 3 year warranty
makes the Aries 6900/7900/8900 Crusader
one of the best Night Vision weapon sights
there is!
FEATURES
ARIES 390 “PALADIN”
• Top-of-the-line First Generation weapon
sight
• New, high resolution Gen. 1+ LIT.
• “Red on Green” reticle system with 1/8
inch @ 100yards adjustment
• 4X magnification with new F:1.4, f90mm
lens
• New, detachable most powerful in the
industry 450mWt Infrared Illuminator with
dedicated windage and elevation adjust-
ments.
• New Titanium mounting system
• Dimensions: 12”x4”x2.8”
• Weight: 2.8 lbs.
ARIES 6900/7900/8900 “CRUSADER”
• Top-notch performance with pro-oriented
design
• 5X magnification, F:1.4, f90mm lens
• “Red on Green” reticle system with 1/8
inch @ 100yards adjustment
• New Titanium mounting system
• Prime Select US 2nd Gen. (6900),
Prime Select US 3rd Gen. (7900) or 4th
Gen.(8900) tubes used
• Automatic brightness control(ABC) for
tube protection
• Dimensions: 12”x4”x3”
• Weight: 2.8 lbs.
• Made in USA
PREPARATION FOR OPERATION
Before getting started make sure to follow
these steps:
• Install the battery into its housing with the
polarity order shown on the main body of
the unit.
• Switch on the Aries scope with the protec-
tive tens cover still attached to the tens.
• Make sure that the green luminance of the
light intensifier tube is present.
• Observe the scene, and adjust the diopter
and/or lens for optimal image clarity.
• You may now enter a dark environment or
simply shut the lights off in order to darken
the room.
• Next, remove the lens cap/daylight filter.
• Observe the scene, and adjust the front
lens for ideal focus.
• Finally, you may want to turn the infra red
(IR) illuminator on. Notice the ability of the
Aries scope to see in total darkness with
the aid of the IR illuminator.
