Asanté FriendlyNET FS4016P Installation Guide
Page
2
Package Contents
1.
Asanté FriendlyNET FS4016P 16-port 10/100M Switch
2.
Self-adhesive rubber pads for desktop installation
3.
AC Power cord
4.
Rack Mounting kit for rack installation
5.
Installation guide
If any of these items are missing, contact your dealer immediately
Installation
The Asanté FriendlyNET FS4016P switch is easy to install and requires no special training. You
should, however, read the following instructions carefully before proceeding to install your switch. The
diagram below shows the layout of the front and rear panels.
Front & Rear Panel of the Asanté FriendlyNET FS4016P
Normal/Uplink
1
8
9
1
16
9
9
16
8
16
Normal/Uplink
9
Full
Auto
8
1
16
9
100-240VAC
Uplink Push Button
Full/Auto dip switches
LED display
FS40016P.fm Page 2 Tuesday, March 16, 1999 5:53 PM
