RH4000-250ES2 c/w Fresh Air Intake
ACCESSORIES INSTALLATION INSTRUCTIONS
Fan Speed
Control
ON / OFF
Switch
Light
Fan Speed
Control
Air
Exhaust
Fresh Air
In
3” dia. collar
Fresh Air
Intake Opening
Baffles
(Must be installed in
exhaust only)
Damper
Exhaust
openings
Electrical Knockout
VERTICAL DISCHARGE ONLY
INSULATION -
Minimum 5 Feet
(1” Thick)
BAFFLE
GRILLE
CAULKING
WALLBOX
NOTE:
3 SIDES ONLY, NOT ON BOTTOM
(IF CAULKING ALL 4 SIDES, MUST HAVE DRAINING HOLES.)
Exhaust
6” dia.
collar
Fresh
Air In
3” dia.
collar
WALLBOX
GRILLE
Insulation
Duct
Pipe
NOTE:
Fresh air intake duct
must be totally insulated
