DISTRIBUTION AMPLIFIER

400-0045-006

4

MECHANICAL

DA1907LX

Material

0.1 in Al

Finish

Gray

Top Panel

Lexan

Height

3.0 in (76 mm)

Width

4.5 in (114 mm)

Depth

1.0 in (25 mm)

Weight

0.5 lb (0.2 kg)

Shipping Weight (approx.)

1.0 lb (0.5 kg)

T

°

Operating

10

°

C-35

°

C

T

°

Maximum

45

°

C

Humidity

90

%

non-condensing

MTBF (calculations)

40,000 hrs

Table 2. DA1907LX Mechanical

ELECTRICAL

DA1907LX

Input Video Signal

Analog Signal Level

1.5 Vp-p max

Impedance

75 ohms

Coupling

DC

Input Sync Signal

Horizontal/Vertical or

Composite

TTL (+/-)

Sync on Green

-0.3 V

Impedance

10 kohms

Output Video Signals

Gain

0 dB +/- 0.5 dB

Impedance

75 ohms

Coupling

DC

Output Sync Signals

Horizontal/Vertical or

Composite

TTL (+/-)

Sync on Green

-0.3 V

Impedance

10 kohms

Power Consumption

External Adapter: 9 VDC

280 mA (2.5 W max.)

Table 3. DA1907LX Electrical
