15
Evolver NE Solventborne Robotic Atomizers - Installation
> Leave 12-24 inches of extra length on all lines
to prevent extreme tension being applied to these
lines during robot movement.
C A U T I O N
!
> Install and route the hoses so that they are
NOT exposed to temperatures in excess of 120 °
F. Ensure that all hose and cable bends are NOT
LESS THAN a 6 inch (15 cm)
radius and are not subjected to more than 360 °
of torsional twist. Failure to comply with these
parameters could cause equipment malfunctions
that might create HAZARDOUS CONDITIONS!
W A R N I N G
!
EVOLVER NE ROBOTIC ATOM-
ZIER INSTALLATION
This information is intended ONLY to indicate the
general installation parameters of this product and,
where applicable, its working relationship to other
Ransburg system components in typical use. Each
installation is unique and should be directed by an
authorized Ransburg representative or conducted
from the Ransburg installation drawings provided
for your particular installation.
APPLICATOR AND
MANIFOLD ASSEMBLY
(See Figure 2)
The tubing and hose come bundled from the factory.
Pull the bundle through the robot spacer plate and
robot wrist carefully to prevent any cuts on the cable
or hoses. Use the six (6) socket head cap screws (7959-
32C) included with the rear manifold tubing assembly
to attach the rear manifold assembly (A11071-XX) to
the robot spacer plate (see Table 1).
Connect each signal line as required per signal iden-
tification, table following.
Robot Spacer Plate
The robot spacer plate is included with the robot
manifold assembly to increase life of the tubing
bundle. The extra spacing it provides, increases the
bend radius of the tubes and decreases the hose or
cable stress at the connector.
There is only one way the spacer plate may be as-
sembled to the mounting plate. The spacer plate has
an alignment pin that may only engage in one hole
position in the robot mount plate. This provides the
INSTALLATION
79107-00 ABB Robots
78983-00 Fanuc P155, 145 Robots
79131-00 Fanuc P200 Robot
A10847-00 Adapter (Kawasaki-KE610L)
A10848-00 Adapter (Motoman-PX2850)
A10849-00 Adapter (Motoman-PX2900)
A10851-00 Adapter (B & M-LZ2000)
Part # Description
TABLE 1 - SPACER PLATES
final position to top head center of the robot.
The six (6) robot spacer plates are available for this
product (see Table 1).
AA-05-01.5
