DR-1 Regulator Assembly
Select Options Below
Ratio 1:1 (1/4-inch Tube)
LREG5001-01
Ratio 1:2 (1/4-inch Tube)
LREG5001-02
Ratio 1:3 (1/4-inch Tube)
LREG5001-03
Ratio 1:4 (1/4-inch Tube)
LREG5001-04
Ratio 1:6 (1/4-inch Tube)
LREG5001-06
Ratio 1:8 (1/4-inch Tube)
LREG5001-08
Ratio 1:10 (1/4-inch Tube)
LREG5001-10
Ratio 1:1 (3/8-inch Tube)
LREG5001-11
Ratio 1:2 (3/8-inch Tube)
LREG5001-12
Ratio 1:3 (3/8-inch Tube)
LREG5001-13
Ratio 1:4 (3/8-inch Tube)
LREG5001-14
Ratio 1:6 (3/8-inch Tube)
LREG5001-16
Ratio 1:8 (3/8-inch Tube)
LREG5001-18
Ratio 1:10 (3/8-inch Tube)
LREG5001-20
1
Cap
LREG0004-01
1
2
Spacer Ring, For:
Select Options Below 1
Ratio 1:1
LREG0003-01
Ratio 1:2
LREG0003-02
Ratio 1:3
LREG0003-03
Ratio 1:4
LREG0003-04
Ratio 1:6
LREG0003-06
Ratio 1:8
LREG0003-08
Ratio 1:10
LREG0003-10
3
Lower Housing
LREG0001
1
4
Screw, Slotted
LSFA0015-00
8
5
Upper Diaphragm Retainer, For:
Select Options Below 1
Ratio 1:1
74155-00
Ratio 1:2
75374-01
Ratio 1:3
75374-06
Ratio 1:4
75374-02
Ratio 1:6
75374-03
Ratio 1:8
74155-00
Ratio 1:10
74155-01
6
Diaphragm Retainer, Lower
74156-00
1
7
Diaphragm Retainer, Center
74231-00
1
8*
Diaphragm, Lower
74273-00
1
9*
Diaphragm, Upper
74157-03
1
10*
O-Ring
Select Options Below
3
.489" ID x .070" C/S, Solvent Resistant
7554-11
.489" ID x .070" C/S, Solvent Proof
79001-08
11
Needle and Seat, Regulating
74160-00
1
12 Spring
74161-00
1
13
Retaining Plug
Select Options Below 1
For 1/4-inch Tube (Use with LSFI0022-04 Fitting)
LREG0005-00
For 3/8-inch Tube (Use with LSFI0022-07 Fitting)
LREG0005-01
14*
Diaphragm, Center
74157-04
1
Item #
DR-1 PLASTIC FLUID REGULATOR - PARTS LIST
(Figures 1 and 3)
Part #
Description
Qty
* Parts contained in Repair Kit
(Continued On Next Page)
DR-1 Plastic Fluid Regulator - Parts Identification
