Serial Digital Module - Introduction
INTRODUCTION
SPECIFICATIONS
Environmental / Physical
Electrical Requirements
Input Voltage:
24 VDC
Input Current:
760 mA
(All valves on)
Input Current
Protection:
Polyfuse (Auto Reset)
Temperature
Operating:
0
o
to 55
o
C
Storage:
-40
o
C to 85
o
C
Humidity:
95% Non-Condensing
(Max.)
Size:
100 x 160mm
Eurocard module,
35mm wide
Pneumatic Input
Input Pressure:
0-100 psi (0-6.8 bar)
Burst Pressure:
250 psi (17.0 bar)
Leak Rate:
1.75 SCFM (Max.)
Req. Filtration:
10 micron
Water Vapor
Content:
1.3 g/m
3
(Max.)
Oil Vapor Content:
0.1 mg/kg (Oil/Water)
(Max.)
Pneumatic Output
Module Flow Rate:
1.9 SCFM
(1 Valve On)
Valve CV Factor:
1.2 SCFM
(All Valves On)
Valve Effective Area:
0.9mm
2
GENERAL DESCRIPTION
The Serial Digital Pneumatic Module converts
electronic signals to eight pneumatic signals. it
is packaged as a Eurocard module and fits into a
Eurocard rack with a 78145 series motherboard.
When configured in retrofit mode, it plugs into a
74847 motherboard. The module has an electri-
cal connector and a quick disconnect pneumatic
connector.
The Serial Digital Pneumatic Module may be com-
manded from any of three sources:
• Serial bus
• Discrete 24 VDC inputs (new or retrofit)
• Ransburg parallel (TTL) bus (for
retrofit applications).
On the module front panel, LED’s indicate when
each valve is energized. Also, the front panel
switches provide momentary manual override for
each valve. These front panel switches can be
locked-out with an on-module switch setting or by
a signal from the electrical connector.
