Part # Description
RECOMMENDED SPARE PARTS (Cont.)
Qty.
A10468-12 Screw M6 X 12mm SS SHCS 2
78449-00 Fitting, Fluid 1
A13030-00 Set Screw M8 X 12mm Cup Pt. SS 2
A12824-00 Cup Wash “Y” Fitting 6
A11252-01 Cup Wash Tubing 10-20 ft.
A12821-00 Cup Wash Fitting 2
A12822-00 Cup Wash Ferrule 4
Select Option Below Fluid Tip Size
A11240-01 .7mm (.028) 1
A11240-02 .9mm (.035) 1
A11240-03 1.0mm (.043) 1
A11240-04 1.2mm (.047) 1
A11240-05 1.6mm (.062) 1
A11240-06 1.0mm (.039) 1
Select Option Below Bell Cup Assembly W/Splash Plate
A13207-00 15mm Titanium (TIS) 1
A12833-00 30mm Aluminum Serrated (ALS) 1
A12942-00 65mm Aluminum Serrated Flip Edge (TISF) 1
Select Option Below Bell Cup Only
A12936-00 15mm Titanium (TIS) 1
A12832-00 30mm Aluminum Serrated (ALS) 1
A12782-00 65mm Aluminum Serrated Flip Edge (TISF) 1
Select Option Below Splash Plate Assembly
A12938-00 For 15mm Bell Cups (White Insert) 2
A11954-00 For 30mm Bell Cups (White) 2
A12071-00 For 65mm Bell Cups (Black) 2
Select Option Below Fluid Coil
79879-00 1/4” OD X .125” ID, PFA, High Conductive Paints (16 Coils) 1
79879-01 1/4” OD X .170” ID, PFA (12 Coils) 1
Aerobell 168 - Parts Identification
Ransburg
LN-9247-13 97
