Vector AA90 Applicators - Introduction
Ransburg
15 AH-07-01.9
SPECIFICATIONS
SOLVENTBORNE
(CLASSIC)
Fluid Pressure: 193 bar (2800 psi)
(maximum)
Fluid Flow Rate: Variable to 1,500 cc/minute
(spray tip dependent)
Air Pressure: 6.9 bar
(0-100 psi) (maximum)
Applicator Length: 2.59cm
(10.2-inches)
Weight: 687.5g
(1.52 lbs.)
(Classic)
Hose and Cable Lengths: 10m, 15m, 20m,
25m, and 30m
Atomizer Assembly: 79581-0XXXX
(See "Nozzle Selection Guide")
Operating Voltage: 85 kV maximum
Current Output:
Classic: 90 microamperes maximum
Paint Resistance:* .1 MW to ∞
Part Sprayability: Determine sprayability of
part to be coated using
Model No. 76652 Test
Equipment
(See "Paint, HV and SCI Test Equipment" service
manaul.)
Consumption: 83.2 dB(A) @ 2.1 bar
(30 psig)
Wetted Parts: Nylon, Acetal, Stainless
Steel, PTFE, and Carbide
*(Use Model No. 76652, Test Equipment)
Environmental/Physical
Electrical
Mechanical
Sound Level
80130-41X 9060 POWER
SUPPLY ELECTRICAL
SPECIFICATIONS
Input Voltage: 100-240 VAC
Current: 1 A maximum RMS
Frequency: 50/60 Hz
Wattage: 40 watts (maximum)
Output Voltage: 20-85 kV DC
Current: 90 microamps (maximum)
Electrical
Height: 16.5cm (6.5-inches)
Width: 37.8cm (14.9-inches)
Depth: 30.7cm (12.1-inches)
Weight: 10.2 Kg (22.5 lbs.)
Physical
Weight: 6.9 bar
(100 psig) (maximum)
Pneumatic
110/120 VAC
220/240 VAC EURO
220/240 VAC CHINA 80130-411
80130-412
80130-413 -85 kV DC
-85 kV DC
-85 kV DC
Voltage
Designation
Maximum
Output
9060
Part #
Control Unit Inputs / Outputs
79581-0XXXX 80130-414
For Use With
9060
Part #
Control Unit / Applicator
Combinations
