Vector Solo 65kV Applicator - Parts Identification
42 AH-08-02.6
(Continued On Next Page)
1 Table D-"D2" Nozzle, Fluid 1
2 80099-00 Assembly, Barrel, Vector Solo 1
3 79907-00 Cascade Assembly 1
4 79832-00 Gasket, Barrel 1
5 79881-00 Gasket, Exhaust, Wrap-Around 1
6 Table D-"D1" Cap, Air 1
7 79724-00 Nut, Retaining, Air Nozzle 1
8 LSOR0005-17 O-Ring, PTFE Encapsulated 1
9 79385-00 Nut, Connector, Hose 2
10 EMF-202-05 Ferrule, Back 3/8" Tube 2
11 EMF-203-05 Ferrule, Front 3/8" Tube 2
12 79878-12 Tube, Fluid Inlet, 3.2mm ID (.125") (Accessory) 1
79878-13 Tube, Fluid Inlet, 3.4mm ID (.250") (Accessory) 1
Table E-"E" Tube, Fluid 1
13 79816-00 Assembly, Rear Cover 1
14 79798-03 SHCS, M5 X 30" 1
15 79799-01 Socket Head Cap Screw, M4 X 25mm 4
16 79798-02 Socket Head Cap Screw, M5 X 80mm 2
17 Table C-"C" Assembly, Trigger 1
18 79454-00 Screw, Trigger Retention 2
19 79768-00 Nut, Fluid Jam, Front 1
20 79774-00 Spring, Air Valve Return 1
21 79701-00 Hook, Molded 1
22 79799-02 SHCS, M4 X 30mm 1
23 Table A-"A" Assembly, Air Hose, Solo (10, 20, and 30m Lengths) 1
24 79833-02 Assembly, Handle, Vector Solo 1
(Includes Items 33, 34, 35, 36, 37, and 38)
24A 79833-03 Assembly, Handle Only 1
25 79835-00 Assembly, Power Module 1
(Includes Items 39, 40, 41, 42, and 43)
26 79768-00 Nut, Fluid Jam, Spring Guide 1
27 78636-00 Spring 1
28 79789-00 Assembly, Rear Fluid Adjustment 1
29 79781-00 Seal, Adjustment Bushing 1
30 79837-00 Gasket, Handle to Power Module 1
31 Table D-"D3" Pressure Reducer, Atomizing Air 1
32 79911-00 Kit, Shaft Assembly, 2-Piece Needle, Vector Solo 1
33 79760-00 Seal, Air Valve 1
34 79769-00 Seal, Air Cartridge 1
35 79770-00 Cartridge, Air Valve 1
36 79759-00 Assembly, Fan Air Adjust Valve 1
37 79772-00 Assembly, Air Valve 1
38 79847-00 Valve, Atom Adjust 1
79847-01 Plug, Atom (Std. installed in applicator) 1
39 79755-00 Fluid Inlet 1
40 79814-00 SHCS, M4 X 20mm 1
41 79836-00 Gasket, Exhaust 1
42 79805-00 Screw 3
43 79843-00 Assembly, Exhaust Housing 1
Item #
VECTOR SOLO 65kV SOLVENTBORNE APPLICATOR -
PARTS LIST (Figure 77)
Part # Description Qty
Ransburg
