12
5. Install side smoker access door handle using one cool grip handle, side door latch (small bend) and nut.
Insert handle through side smoker door as shown in Figure 5. Keep cool grip handle horizontal. Place
side door latch (small bend) over threaded end of handle on back side of side smoker door. The bend on
latch should be pointed down (See Figure 6 Below). Tighten with supplied nut. Turn side access door
handle down to latch in place.
6. Install cabinet thermometer on front smoker door. Remove brass nut from stem of thermometer and
insert stem through the front of the smoker door in hole provided. Reattach nut to thermometer stem on
inside of door to tighten. See below Figure 7 for proper thermometer placement.
7. Go to the Use and Care Section of this manual for further instructions.
Figure 5
Figure 6
Figure 7
Thermometer
