Havener E-40 Edger - Manual (Page 10)

10
Starting The Engine
1. Be sure the clutch lever is in the rearward DISENGAGED position before starting the engine. (Fig 1)
2. Manually set the choke to the “CLOSED” position on the engine (Fig 2)
3. Turn engine switch to “ON”. (Fig 3).
4. Grasp the recoil starting handle and pull quickly. Return the handle slowly. If the engine fails to start after
three or four pulls, push the throttle down to the detent full throttle (Fast) position.
5 Once the engine starts, push the choke to the “OPEN” position.
CAUTION : Always start the edger/trimmer slowly. Sudden starts can be damaging to the
equipment and could cause loss of operator control. !
Disengage
blade by
using last
slot on top
Choke lever
Fuel
lever
Figure 1 Figure 2
Figure 3
Engine Switch ON
