Havener 22DP22BP24SP with Vertical Shaft Engine - Manual (Page 18)

Item No. Part Number Description Qty
1 410-001 Spacer Sleeve 4
2 15005 Bronze Pivot Bushing 4
3 410-002 Castor Support 2
4 200-026 Grease Fitting M6 GB1152-89 2
5 15031 Washer 2
6 15023 Lynch Pin Tire 2
7 410-003 Castor Yoke 2
8 400-008 Front Wheel Axle 2
9 200-071 Plain Washer 12 GB95-85 4
10 400-009 Front Wheel 2
11 200-007 Nylon Nut M12 GB889-86 2
12 200-006 Nylon Nut M10 GB889-86 4
13 200-019 Hexagon Bolt M10×40 GB5782-86 4
14 200-178 Hexagon Bolt M8×16 GB5783-86 2
15 200-040 Mulch plate 1
16 200-030 Nylon Nut M8 GB889-86 2
17 410-000 Swivel Wheel Kit
18 400-041 Mulch plate Assembly
