Section 1: General Information
8/09 12 51198 Rev. 2
AEGIS INDUSTRIAL MILD STEEL FLOOR SCALE
Description, Features and Applications
Three inches (3”) height and 2-1/2’ x 2-1/2’ to 6’ x 8’ design allows for
material handling equipment access such as drum movers, pallet jacks and fork lifts.
Load cell capacity is
1,000 to 5,000 lbs. Used for applications such as General
Industrial, Inventory Management, Pallet Weighing, and Shipping/Receiving.
SPECIFICATIONS
Scale Capacities 1,000 to 10,000 lbs.
Platform 1/4” plate with diamond tread
Platform height 3.0” on all models
Overload capacity 150% of capacity
Endloading 100% of capacity
Platform Construction Type A36 industrial-grade carbon steel
Paint Gray epoxy, ester enamel
Load Cell Capacity 1,000 to 5,000 lbs
Load Cell Construction Alloy tool steel*
* Scale uses stainless steel load cells on 30” x 30” – 1,000 lbs.
and 6’ x 8’ – 9,990 lbs. scales.
CABLE COLOR CODE
GREEN (+) EXCITE
BLACK (-) EXCITE
RED (-) SIGNAL
ACCESSORIES
• Ramps
• Bolt-down Plate
• Pit Frame
• Lifting Eyebolts
• SS Eyebolt Hole Plugs
• Bumper Guards
MODIFICATIONS
• Smooth Deck and
Ramps
• Lower Capacity Load
Cells
• Custom Platform, Ramp
and Pit Frame sizes
• Lifting Handles
