Typical code = b15. 01. p t. b b. e t p - t – Blagdon Pump X15 Non-Metallic User Manual
Page 4

HG-CF-961 Rev. U - 08.07.14
PAGE 4
FLUID CONNECTIONS
CAPACITY
MAX SOLIDS
MAX DISCHARGE HEAD
DISPLACEMENT/STROKE
1/2” ANSI 150 / DN15
Compatible Flange
0 - 48 Litres/Minute
(0 - 10.5 Gallons/Minute)
2 MM
(5/64”)
88 Meters
(289 ft)
0.075 Litres
(0.02 UK Gallons)
MAX. WORKING PRESSURE
AIR INLET
TEMPERATURE LIMITS
PUMP WEIGHTS :-
8.0 Bar (116 psi)
1/4” BSP (F)
Polypropylene :- 70
o
C
PVDF (Kynar) :- 90
o
C
PT/GT :- 4.0 Kg
KT :- 5.0 Kg
TECHNICAL DATA
Caution -
Operating temperature limitations are as follows:
Operating Temperatures
Materials
Maximum
Minimum
Optimum
Buna-n -
General purpose, oil resistant. Shows good solvent, oil, water and hydraulic fluid resistance. Should not
be used with highly polar solvents like acetone and MEK, ozone, chlorinated hydrocarbons and nitro hydrocarbons.
176
o
F
80
o
C
-18
o
F
-28
o
C
50
o
to 140
o
F
10
o
to 60
o
C
EPDM -
Shows very good water and chemical resistance. Has poor resistance to oils and solvents, but is fair on
ketones and alcohols.
212
o
F
100
o
C
-11
o
F
-24
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Neoprene -
All purpose. Resistant to vegetable oil. Generally not affected by moderate chemicals, fats greases
and many oils and solvents. Generally attacked by strong oxidising acids, ketones, esters, nitro hydro carbons and
chlorinated aromatic hydrocarbons.
212
o
F
100
o
C
-4
o
F
-20
o
C
50
o
to 130
o
F
10
o
to 54
o
C
Santoprene® -
Injection moulded thermoplastic elastomer with no fabric layer. Long mechanical flex life.
Excellent abrasion resistance.
212
o
F
100
o
C
-10
o
F
-23
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Virgin PTFE -
Chemically inert, virtually impervious. Very few chemicals are known to react chemically with
PTFE : molten alkali metals, turbulent liquid or gaseous fluorine and a few fluoro-chemicals such as chlorine trifluo-
ride or oxygen difluoride which readily liberate free fluorine at elevated temperatures.
356
o
F
180
o
C
32
o
F
0
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Viton® -
Shows good resistance to a wide range of oils and solvents : especially all alphatic, aromatic and
halogenated hydrocarbons, acids, animal and vegetable oils.
356
o
F
180
o
C
0
o
F
-18
o
C
75
o
to 212
o
F
24
o
to 100
o
C
Polypropylene -
High strength, light weight, corrosion resistant polyolefin which easily withstands most chemi-
cals, with no known solvent at room temperature.
158
o
F
70
o
C
-40
o
F
-40
o
C
50
o
to 140
o
F
10
o
to 60
o
C
TYPICAL CODE =
B15. 01. P T. B B. E T P - T
WETTED COMPONENTS
P : POLYPROPYLENE
G : CONDUCTIVE POLY. (ATEX CAT.2)
K : PVDF (KYNAR)
NON - WETTED COMPONENTS
T : ALUMINIUM / EPOXY CTD
VALVE TYPE
B : BALL
SUCTION ORIENTATION
B : BOTTOM
VALVE SEATS
B : BUNA-N
P : POLYPROPYLENE
E : EPDM
D : DELRIN
N : NEOPRENE
K : PVDF (KYNAR)
V : VITON
VALVE BALLS
B : BUNA-N
S : 316 ST. STEEL
D : DELRIN (ACETAL)
T : PTFE
E : EPDM
V : VITON
N : NEOPRENE
DIAPHRAGMS
B : BUNA-N
P : POLYURETHANE
E : EPDM
R : SANTOPRENE
H : POLYESTER
T : PTFE
N : NEOPRENE
V : VITON
O : ONE PIECE PTFE
DESIGN LEVEL
MODEL
B15 : STANDARD
X15 : ATEX CAT. 2
TAPPED MANIFOLDS
IMPORTANT
This pump should be used in accordance with the requirements of the Safety, Health & Welfare at Work Act 2005.
All business conducted subject to IDEX Pump Technologies, Ireland. Terms and Conditions of Sale, available on request.
IDEX Pump Technologies (Ireland) Ltd.,
A Unit of IDEX Corporation,
R79, Shannon, Co Clare, IRELAND.
TEL. : +353 61 471933 FAX. : +353 61 475046
