Blagdon Pump B15 Stainless Steel - Manual (Page 2)

PARTS LIST
REF
No.
PART NUM-
BER
DESCRIPTION QTY
1 SEE TABLE SUCTION MANIFOLD 1
2 SEE TABLE O-RING (VALVE SEAT) 4
3 SEE TABLE VALVE SEAT 4
4 SEE TABLE VALVE BALL 4
5 SEE TABLE OUTER COVER 2
6 SEE TABLE FRONTPLATE ASSEMBLY 2
7 SEE TABLE DIAPHRAGM 2
8 SEE TABLE DISCHARGE MANIFOLD 1
9 1H114 BACKPLATE 2
10 15-200 CENTRE SECTION 1
11 D250 SOCKET CAP SCREW M6 x 12 4
12 C174 WASHER M6 4
13 H125 CIRCLIP 2
14 -
15 G189 O-RING 4
16 15-182 DIAPHRAGM SHAFT BUSH 2
17 15-295 4
18 SA10036 DIAPHRAGM SHAFT ASSEMBLY 1
19 D053 SOCKET CAP SCREW M6 x 45 8
20 C007 WASHER M6 20
21 D266 SOCKET CAP SCREW M6 x 35 12
22 06-034 SILENCER 1
23 1H020 CENTRE SECTION GASKET 1
24 15-202 VALVE BLOCK PLUG 2
25 G020 O-RING ( V.B. PLUG) 2
26 15-201 VALVE BLOCK 1
27 1H009 VALVE CARRIER 1
28 1A025 SLIDE VALVE 1
29 D209 COUNTERSUNK SCREW M4 x 12 4
30 15-001 SLIDE VALVE PLATE 1
31 B272 SQUARE NUT M6 12
32 15-219 BACK-UP DIAPHRAGM 2
33 15-033 PTFE DIAPHRAGM 2
DIA. SHAFT SEAL (SEE TABLE FOR LUBE FREE OPTION)
PARTS LIST - cont.
NOTES
ELASTOMER TABLE
REF. No. 2 3 4 7
DESCRIPTION O-RING VALVE SEAT VALVE BALL DIAPHRAGM
MATERIAL
BUNA-N G251 15-002 15-017 1H011
NEOPRENE G437 15-003 15-014 1H049
EPDM G394 15-004 15-015 1H206
VITON G395 15-005 15-016 1H051
PTFE G429 - 1H017 REF. 32 & 33
POLYESTER - - - 1H022
POLYURATHANE - - - 1H050
POLYPROPYLENE - 15-025 - -
DELRIN - 15-054 1H072 -
SANTOPRENE
® - - - 15-219
ONE-PIECE PTFE - - - 15-195
- These items are available in a recommended spares kit. Please refer to your local stockist / distributor
for details.
- These items are available in a recommended spares kit - ASK15SS - Air side Kit.
Lube Free Air Side Kit - ASK15SS-LF
- These items are supplied as Sub-Assy. SA10435
NOTE! When using rubber valve seats (3), item 2 o-ring is not required.
Santoprene is a registered tradename of Monsanto Corp.
WETTED COMPONENTS
REF
No.
DESCRIPTION POLYPROPYLENE PVDF QTY
1 SUCTION MANIFOLD 15-024 15-059 15-063 15-075 1
5 OUTER COVER 15-022 15-061 2
6 FRONTPLATE 15-021 15-062 2
8 DISCHARGE MANIFOLD 15-023 15-058 15-064 15-076 1
1/2” BSP(T) THREADED OPTIONS
LUBE FREE COMPONENTS
REF
No.
DESCRIPTION PTFE QTY
17 O-RING (CENTRE SECTION) 15-018 4
