Specifications
Function ACS-1208L ACS-1216L
Computer
Connections Direct 8 16
Max 504 (via Daisy Chain) 512 (via Daisy Chain)
Port Selection OSD (On Screen Display); Hotkeys
LEDs On Line Port 8 (Orange) 16 (Orange)
Selected Port 8 (Green) 16 (Green)
Power 1 (Blue)
Computer Port Connectors 8 x SPDB-15 F 16 x SPDB-15 F
Daisy Chain Ports 1 x DB-25 M
Scan Interval (OSD Select) User Specified: 1 - 255 secs.
Emulation Keyboard PS/2
Mouse PS/2
Video 1024 x 768
Power Consumption 120V 60Hz 24W;
230V 50Hz 24W
Operating Temperature 0 - 50
o
C
Storage Temperature -20 - 60
o
C
Humidity 0 - 80% RH
Housing Metal
Weight 11.5 Kg 12.0 Kg
Dimensions (L x W x H) 483 x 517 x 45 mm (19" 1U)
2002-01-15
30 ACS-1208L / ACS-1216L User Manual
