FLUID CONNECTIONS
CAPACITY
MAX SOLIDS
MAX DISCHARGE HEAD
DISPLACEMENT/STROKE
DIN 50 Tri-Clamp size
Other options available (RJT/DIN)
0 - 320 Litres/Minute
(0 - 70 Gallons/Minute)
6 MM
(1/4”)
88 Meters
(289 ft)
1.2 Litres
(0.3 UK Gallons)
MAX. WORKING PRESSURE
AIR INLET
TEMPERATURE LIMITS
PUMP WEIGHTS :-
8.6 Bar (125 psi)
3/8” BSP (F)
Determined by Elastomers
SA :- 42 Kg
SS :- 49 Kg
TECHNICAL DATA
Caution -
Operating temperature limitations are as follows:
Operating Temperatures
Materials
Maximum
Minimum
Optimum
Buna-n -
General purpose, oil resistant. Shows good solvent, oil, water and hydraulic fluid resistance. Should not
be used with highly polar solvents like acetone and MEK, ozone, chlorinated hydrocarbons and nitro hydrocarbons.
176
o
F
80
o
C
-18
o
F
-28
o
C
50
o
to 140
o
F
10
o
to 60
o
C
EPDM -
Shows very good water and chemical resistance. Has poor resistance to oils and solvents, but is fair on
ketones and alcohols.
212
o
F
100
o
C
-11
o
F
-24
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Neoprene -
All purpose. Resistant to vegetable oil. Generally not affected by moderate chemicals, fats greases
and many oils and solvents. Generally attacked by strong oxidising acids, ketones, esters, nitro hydro carbons and
chlorinated aromatic hydrocarbons.
212
o
F
100
o
C
-4
o
F
-20
o
C
50
o
to 130
o
F
10
o
to 54
o
C
Santoprene® -
Injection moulded thermoplastic elastomer with no fabric layer. Long mechanical flex life.
Excellent abrasion resistance.
212
o
F
100
o
C
-10
o
F
-23
o
C
50
o
to 212
o
F
10
o
to 100
o
C
PTFE -
Chemically inert, virtually impervious. Very few chemicals are known to react chemically with PTFE :
molten alkali metals, turbulent liquid or gaseous fluorine and a few fluoro-chemicals such as chlorine trifluoride or
oxygen difluoride which readily liberate free fluorine at elevated temperatures.
356
o
F
180
o
C
32
o
F
0
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Viton® -
Shows good resistance to a wide range of oils and solvents : especially all alphatic, aromatic and
halogenated hydrocarbons, acids, animal and vegetable oils.
356
o
F
180
o
C
0
o
F
-18
o
C
75
o
to 212
o
F
24
o
to 100
o
C
VALVE SEATS
S : 316 STAINLESS STEEL
VALVE BALLS
E : EPDM
T : PTFE
S : 316 STAINLESS STEEL
DIAPHRAGMS
E : EPDM
T : PTFE
O : ONE PIECE PTFE
MODEL
B40 : STANDARD
X40 : ATEX CAT. 2
WETTED COMPONENTS
S : 316L STAINLESS STEEL
NON - WETTED COMPONENTS
A : ALUMINIUM
S : STAINLESS STEEL
VALVE TYPE
B : BALL
SUCTION ORIENTATION
B : BOTTOM
SUFFIX
P : BSP CONNECTIONS
P1: TRI-CLAMP CONNECTIONS
ELECTRO - POLISHED
TYPICAL CODE =
B 40.05. S A. B B. E T S - P
