Typical code = b50. 05. z f. b b. e e e – Blagdon Pump X50 Hygienic User Manual
Page 4

Gentle pumping action to avoid damage to food and
beverage products.
Range of RJT/DIN/FERRULE/SMS connections.
Self priming for emptying containers.
Lube-Free as standard.
Food grade elastomers – EPDM/PTFE
Pressures to 8.6 bar.
Capable of handling high viscosity & SG fluids.
Certified CIP cleanable.
EU Design approval
316L Stainless steel
Pump Stand option for 180° rotation in place.
Caution -
Operating temperature limitations are as follows:
Operating Temperatures
Materials
Maximum
Minimum
Optimum
EPDM -
Shows very good water and chemical resistance. Has poor resistance to oils and solvents, but is fair on
ketones and alcohols.
212
o
F
100
o
C
-10
o
F
-23
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Virgin PTFE -
Chemically inert, virtually impervious. Very few chemicals are known to react chemically with
PTFE : molten alkali metals, turbulent liquid or gaseous fluorine and a few fluoro-chemicals such as chlorine
trifluoride or oxygen difluoride which readily liberate free fluorine at elevated temperatures.
212
o
F
100
o
C
-35
o
F
-37
o
C
50
o
to 212
o
F
10
o
to 100
o
C
FLUID CONNECTIONS
CAPACITY
MAX SOLIDS
MAX DISCHARGE HEAD
DISPLACEMENT/STROKE
2” RJT Male
0 - 476 Litres/Minute
(0 - 105 Gallons/Minute)
6 MM
(1/4”)
88 Meters
(289 ft)
1.9 Litres
(0.42 UK Gallons)
MAX. WORKING PRESSURE
AIR INLET
TEMPERATURE LIMITS
PUMP WEIGHTS :-
8.6 Bar (125 psi)
3/4” BSP (F)
Determined by Elastomers
ZF :- 42 Kg
TECHNICAL DATA
WETTED COMPONENTS
Z : 316L STAINLESS STEEL
(POLISHED)
DESIGN LEVEL
NON - WETTED COMPONENTS
F : NICKEL PLATED ALUMINIUM
S: 316L STAINLESS STEEL
VALVE TYPE
B : BALL
SUCTION ORIENTATION
B : BOTTOM
VALVE SEATS
E : EPDM (FOOD GRADE)
T : PTFE
VALVE BALLS
E : FOOD GRADE EPDM
T : PTFE
S : 316 STAINLESS STEEL
DIAPHRAGMS
E : EPDM (FOOD GRADE)
MODEL
B50 : STANDARD
X50 : ATEX CAT.2
TYPICAL CODE =
B50. 05. Z F. B B. E E E
