5.2 Configuration
5.2.1 Monitor Setup
Calibration of the HD class A reference monitor
The HD Monitor that has been used for the color timing
shall be calibrated according to the following guidelines:
• The color temperature shall be 6500K
• 100% white shall be at a luminance of 80 cd/m 2 .
• 20% gray shall be at a luminance of 2.2 cd/m 2
The following two test images are needed for the
calibration procedure:
calibration image luminance Y U V
20% gray 2.2 cd/ m 2 240 512 512
100% white 80 cd/m 2 940 512 512
Note : We recommend the use of a high quality color
calibration sensor, e.g. a Philips PM 5639.
5.2.2 Film Setup
The vision print film profile is established under the
following circumstances:
• Recorded on Kodak 5242 intermediate film stock
• Recorder calibrated to carlos.aim
• Printed on Kodak Vision print stock
• LAD frame (Aqua 0015) printed to
1.09 1.06 1.03 densities
Color Management
