Audiovox APS 600 - Manual (Page 8)

RED
87A
85 86
30
CUT
TO
IGNITION
SWITCH
TO
START
SOLENOID
87
TO +12 VDC
IGN./CRANK
EXISTING LOW CURRENT SOLENOID
FEED WIRE (+12VDC, CRANKING ONLY)
APS-600
CONTROL
MODULE
SHOCK SENSOR
Red, Black, Blue, and
Green WIres.
ORANGE
TRUNK RELEASE
Connect to +12 VDC Battery for
Positive Switched Trunk Release
or
Chassis Ground for Negative
Switched Trunk Release
DARK BLUE
GROUND SOURCE
Connect to Vehicle's Chassis
BLACK
GREEN w/WHITE
DOME LIGHT
EXISTING
DOOR PIN SWITCH
ENTRY ILLUMINATION
Connect to +12 VDC Battery
for Positive Switched Dome
Light or Chassis Ground for
Negative Switched Dome Light
WHITE
+12 VDC BATTERY
Connect to a +12 Volt
Battery Source.
(See Note on Voltage
Sensing)
EXISTING PARKING LIGHT
DOOR LOCK
OUTPUTS
BLUE
w/WHITE
GREEN YELLOW ORANGE
WHITE BLUE
EXISTING SWITCHED
OUTPUT
DARK BLUE
EXISTING TRUNK
RELEASE SWITCH
Page 8
RED
RED
5A
FUSE
RED w/
WHITE
15A
FUSE
SIREN
GREEN w/WHITE
BLACK
(-) TO VEHICLE'S
CHASSIS GROUND
WHITE w/BLACK
BLACK
