1000-TH-I •
InsTallaTIon
/
operaTIon
/
servIce manual
-
pg
. 7
ELECTRICAL
voltage phase cycle / hz amps kW cord and plug
208-240 ( agcy ) 1 60 28.8 6.0
no cord
at 208 1 60 28.9 6.0
or plug
at 240 1 60 22.2 5.3
230 ( agcy ) 1 50 21.3 4.9
no cord or plug
The appliance must be installed by a qualified
service technician. The oven must be properly
grounded in accordance with the National Electrical
Code and applicable local codes.
Plug the unit into a properly grounded receptacle
ONLY, positioning the unit so that the plug is easily
accessible in case of an emergency. Arcing will
occur when connecting or disconnecting the unit
unless all controls are in the “
off
” position.
Proper receptacle or outlet configuration or
permanent wiring for this unit must be installed by
a licensed electrician in accordance with applicable
local electrical codes.
With the voltage conversion switch in the 200-208V
(UPPER) position, the oven will function properly
with a source voltage of between 200 and 208.
With the voltage conversion switch in the 220-240V
(LOWER) position, the unit will function properly
with a source voltage of between 220 and 240.
NOTE: ALL 208-240V units are shipped from the
factory with the voltage conversion switch
in the 220-240 position.
All 125V rated units will function properly with a
source voltage of between 100 and 125, 60 Hz.
The 125V rated units are provided with a cord
and plug [NEMA #5-20P]. Have a licensed
electrician install the proper outlet configuration as
required for the unit in accordance with applicable,
local electrical codes. This will assure a safe and
trouble-free installation.
Ensure that the voltage conversion switch position
and the available power source match.
230V:
To prevent an electrical shock hazard between
the appliance and other appliances or metal parts
in close vicinity, an equalization-bonding stud is
provided. An equalization bonding lead must be
connected to this stud and the other appliances /
metal parts to provide sufficient protection
against potential difference. The terminal is
marked with the following symbol.
NOTE: 230V appliances must be connected to
an electrical circuit that is protected by
an external GFCI outlet.
E L E C T R I C A L C O N N E C T I O N
I N S T A L L A T I O N
D A N G E R
ENSURE POWER SOURCE
MATCHES VOLTAGE STAMPED
ON APPLIANCE NAMEPLATE.
D A N G E R
To avoid electrical shock, this
appliance MUST be adequately
grounded in accordance with local
electrical codes or, in the absence of
local codes, with the current edition
of the National Electrical Code ANSI/
NFPA No. 70. In Canada, all electrical
connections are to be made in
accordance with CSA C22.1, Canadian
Electrical Code Part 1 or local codes.
D A N G E R
ELECTRICAL CONNECTIONS MUST
BE MADE BY A QUALIFIED SERVICE
TECHNICIAN IN ACCORDANCE WITH
APPLICABLE ELECTRICAL CODES.
Wire diagrams are located inside the bonnet of the unit .
