enFORCE SAN Unit Operation Manual
PAGE 6 - 19
Chapter 6: System Operation
Data Number Conversion Table
Item
Parameter
Number
PARM
Data
Number D-
No
DATA
System
００ ００ Load unit number ０ :ＫＮ 1: Klbs. 2: Metric Ton
００ ０１ ＳＰ version／copy between parameter
００ ０２ Amplifier Version
００ ０３ Function Version
００ ０４ Off Set Load
００ ０５ Distance Compensation ［mm］
００ ０６ No Load Current Limit 0～1023
００ ０７ Home Position Off Set ［mm］
００ ０８ Home Position Sensor／PLC Bank Select
００ ０９ Home position search time out 0.1[sec] unit
００ ０Ａ Distance Decimal / Deadman / Comm Speed / Timing Signal
００ ０Ｂ Approach Distance Limit／Load Cell Availability
００ ０Ｃ Current Load Conversion Ratio [%]
００ ０Ｄ Stroke Distance Limit／Load Hold Time Decimal Point
００ ０Ｅ MANUAL Speed ［mm/sec］
００ ０Ｆ Dynamic Hold / RS232C Output／Speed Decimal Point
Tool
Data
００ １０ Tool Number
００ １１ Tool CAL Load
００ １２ Tool CAL Voltage [Ｖ]
００ １３ Tool Zero Load Voltage [Ｖ]
００ １４～１Ａ In House Control Data
Tool Type ００ ２０ Tool Number
０１～３２ ００ Press Mode (Press Method + Return Operation+ Judgment Operation)
Load
０１～３２ １０ Full-Scale Load
０１～３２ １１ Load Low Limit
０１～３２ １２ Load High Limit
０１～３２ １３ Target Load
０１～３２ １４ Press Speed Start Load
０１～３２ １５ Interference Check Load / Part Check Load High Limit
０１～３２ １６ Distance Measurement Start Load
０１～３２ １７ Part Check Load Low Limit
０１～３２ １８ Detection Start Load/Time Start Load (2 nd Rate Start Load)
Distance
０１～３２ ２０ Distance Low Limit [mm]
０１～３２ ２１ Distance High Limit [mm]
０１～３２ ２２ Target Distance [mm]
０１～３２ ２３ Interference Check Distance / Part Check Distance [mm]
０１～３２ ２４ Press Speed Start Distance [mm]
Special Option
０１～３２ ３０ Advance Position ON Distance (1 st Rate Low) [mm]
０１～３２ ３１ Advance Position OFF Distance (1 st Rate High) [mm]
０１～３２ ３２ Return Position ON Distance (2 nd Rate Low) [mm]
０１～３２ ３３ Return Position OFF Distance (2 nd Rate High) [mm]
Time
０１～３２ ４０ Slow Start Time [sec]
０１～３２ ４１ 1 ST Time High Limit [sec]
０１～３２ ４２ 2 ND Time High Limit / Press Time [sec]
Speed
０１～３２ ５０ Slow Start Speed [mm/sec]
０１～３２ ５１ Approach Speed [mm/sec]
０１～３２ ５２ Part Search Speed [mm/sec]
０１～３２ ５３ Press Speed [mm/sec]
０１～３２ ５４ Return Speed [mm/sec]
０１～３２ ６０ Approach Distance [mm]
Special Setting
０１～３２ ６１ Load Hold Time [sec]
０１～３２ ６２ Job Start Position [mm]
０１～３２ ６３ Load Change
０１～３２ ６４ Distance Off Set [mm]
