enFORCE Operation Manual
PAGE 8 - 12
Chapter 8: Troubleshooting
8.9 Parameter Errors [ A9_* ]
• Code A9_0 - PARAMETER ERROR / MISSING SPEED PRESET
Some speed preset is not set up in the parameter number selected or the wrong parameter
number has been selected by the PLC.
RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the speed presets are not <0> or out of the specified speed range of the tool.
• Code A9_1 - PARAMETER ERROR / MISSING TIME or SPEED PRESET
Some Time or Speed preset is not setup in the parameter number selected or the wrong
parameter number has been selected by the PLC.
RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the time or speed presets are not set as <0> or out of the specified speed range
of the tool.
• Code A9_2 - PARAMETER ERROR / PARAMETER SELECT ERROR
The parameter selected was empty.
RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the press presets are not <0> or out of the specified range for the tool.
• Code A9_3 - PARAMETER ERROR / MISSING RETURN SPEED
The Return Speed preset is missing.
RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the Return Speed is not set as <0> or out of the specified range for the tool.
• Code A9_4 - PARAMETER ERROR / PRESS SPEED NOT SET
The Press Speed preset is missing.
RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the Press Speed is not set as <0> or out of the specified range for the tool.
• Code A9_5 - PARAMETER ERROR / LOAD SETUP ERROR
One of the Load presets is out of range.
RECOVERY:
1. Verify that the Load presets are in range for the tool size.
2. Check that the load presets are not <0> or setup as specified in 6.4.5.2.
