switches are set to the NORMAL position. Press the REV button on the Main
Unit to operate all spindles simultaneously as verification of sufficient input power.
4. Verify operation of manual start.
P Press the START button on the Main Unit and verify that all tools run in the correct
direction until the pre-programmed time elapses, creating both a TIME reject and a
TORQUE reject. The Main Unit "REJECT" light will illuminate, and the LEDs
marked TIME and TORQUE on each Axis Unit will light (orange). (See NOTE3).
P Press the RESET button on the Main Unit to clear the REJECT light and LED
outputs from the Axis Units.
NOTE 3: If any Axis Unit fails to indicate a TIME and/or TORQUE reject (and assuming the previous
verifications were completed), then verify that the correct presets have been entered into
the System for that spindle. Reference Section 7.2 Limit Parameter for guidance.
5. Verify System operation by external commands.
{ Confirm that the equipment operates correctly when PLC inputs and outputs are activated.
Use the PLC to perform all of the functions (START, CAL, etc.) that were manually
activated earlier in this Section.
Chapter 5: Power Up and Initial Checks User Console Version A3.53
Page 5-5
