200~230 VAC +/- 10%, 50/60 Hz, single phase input power
connector. AC200~230V 22
DSUB 25-pin female Centronics parallel port connector. PRINTER 21
3.5" 1.44MB Floppy Disk Drive (notebook computer style). FDD1 / FDD2 20
2" IDE Hard Disk Drive (notebook computer style). Size may
vary dependent upon availability. HDD1 (INSIDE - NOT VISIBLE) 19
DSUB 9-pin male RS232C input connector. RS232C CH2 18
DSUB 9-pin female RS422 communications connector. RS422 17
DSUB 15-pin female VGA CRT connector. CRT 16
Connector for optional Liquid Crystal Display (LCD). LCD 15
Backup battery (3-year life). (INSIDE - NOT VISIBLE) 14
MINI DIN 6 pin keyboard/keypad connector. K/B 13
Interface connector for System input/output control lines.
Refer to Chapter 4 for detailed input and output descriptions. PLC 12
Manual Calibration (Cal) Check pushbutton. (MANUAL) CAL 11
Manual reverse pushbutton. (MANUAL) REV 10
Manual fastening start pushbutton. (MANUAL) START 9
Manual Zero Check and System reset pushbutton. (MANUAL) RESET 8
Operating mode selector (key) switch. Set to RUN for normal
operation, and set to PROGRAM to enter data. RUN / PROGRAM 7
Rotary switch for selecting which items are to be displayed at
Axis Unit DSP1 and DSP2. (Refer to the Axis Unit Display
Table in this Chapter) AXIS-DSP 6
Display LED (Orange) that indicates when either a Cal Check
or a Zero Check is being performed. CHECK 5
Display LED (Orange) that indicates when the fastening cycle
is in process. BUSY 4
Display light that indicates when an unacceptable fastening is
complete. REJECT 3
Display light that indicates when an acceptable fastening is
complete. ACCEPT 2
DSUB 9-pin male RS232C output connector. RS232C CH1 1
Description Item as called out on Figure 3.2.3
MAIN CONTROL UNIT CONTROLS AND INDICATORS
Chapter 3: System Description User Console Version A3.53
Page 3-7
