Replacement Parts
Compact Undercounter Refrigerators & Freezers
Part No. Description UR-27 UR-48 UF-27 UF-48
Doors & Components
55113501 Door Assembly, RH X X
55113502 Door Assembly, LH X X
55113601 Door Assembly, RH X X
55113602 Door Assembly, LH X X
55114401 Door Assembly with Locks, RH X X
55114402 Door Assembly with Locks, LH X X
55114403 Door Assembly with Locks, RH X X
55114404 Door Assembly with Locks, LH X X
55113505 Door Assembly with Dial Thermometer, RH X X
55113506 Door Assembly with Dial Thermometer, LH X X
55115001 Latch Assembly X X
50630601 Gasket X X
50630602 Gasket X X
50635201 Gasket Retainer, Door Sides X X X X
50635202 Gasket Retainer, Top & Bottom X X
50635203 Gasket Retainer, Top & Bottom X X
50635301 Liner, Inner Door X X
50635302 Liner, Inner Door X X
Drawers & Components
(URD 27’s)
55113703 Drawer Assembly, Lower X
55113704 Drawer Assembly, Upper X
50630603 Gasket, Drawer (Product) X
50635202 Gasket, Retainer, Drawer, Top & Bottom X
50635201 Gasket, Retainer, Drawer, Side X
50714801 Pan, Drawer (12 x 20 x 6) X
50635303 Pan, Drawer X
55113901 Front Assembly, Drawer X
55114701 Track, Drawer Slide, Right X
55114702 Track, Drawer Slide, Left X
05109902 Channel, Slide Support X
55114303 Slide Support Assembly with Rollers, Left X
55114304 Slide Support Assembly with Rollers, Right X
50543803 Roller Bearing, Slide Support X
09145901 Bracket, Drawer Slide Lower Front, Left X
09145902 Bracket, Drawer Slide Lower Front, Right X
09146001 Bracket, Drawer Slide Upper Front, Left X
09146002 Bracket, Drawer Slide Upper Front, Right X
19
Section 6-Parts List Section 6-Parts List
