Teledyne AX300-I - Medical application oxygen analyzer User Manual
Page 5

Portable Oxygen Analyzer
Teledyne
Analytical
Instruments
v
Table of Contents
Safety Messages .......................................................................... iv
List of Figures .............................................................................. vii
List of Tables .............................................................................. viii
Introduction ................................................................................... 1
1.1 Features
2
1.2 Options
3
1.3 Applications
3
1.4 Operation Summary
3
Operating Instructions .................................................................. 5
2.1 Setup
5
2.1.1 Sensor Installation or Replacement
5
2.1.2 Mounting
7
2.1.2.1 V-Mount Adapter Installation
7
2.1.2.2 Universal Mounting Clamp Installation
8
2.1.3 Battery Installation
8
2.1.4 Calibration
9
2.1.5 Output 0-1 VDC or RS232
11
2.2 Operating Instructions
13
2.2.1 Procedure
13
2.3 Factors Affecting Sampling Accuracy
14
2.3.1 Humidity
14
2.3.2 Temperature
15
2.3.3 Pressure
15
2.3.4 Discrepancy in Readings
15
2.3.5 Anesthetic Gases
16
2.3.5.1 Gases That MAY INDUCE Reading Error
16
2.3.5.2 Care After Use in Nitrous Oxide
17
2.3.6 Cleaning
17
2.4 Dos and Don’ts
17
Service Instructions .................................................................... 19
