Model LXT-230 Instruction Manual / 18
7.0 LXT-230 MODEL NUMBER DESIGNATORS
Channel 1 Input & Output
LXT-230-PH/MA pH
LXT-230-OR/MA ORP
LXT-230-PION/MA Specific Ion
(see note 1)
Note 1: For PION, the model number will
reflect the ion being measured; for
example, Ca for calcium, Fl for
fluoride, etc.
Channel 2 Input
PH
pH
OR ORP
PION Specific Ion (see note 1)
DO Dissolved Oxygen
Channel 2 Output
MA 4-20 mA, standard
PID 4-20 mA, 3-mode PID control
TMP1 4-20 mA, Temperature (adjustable
-100° to +200°C)
Channel 3 Output
TMP1 Only output available on this
channel.
Mounting Hardware
UM Universal mounting plate
PM Panel mounting hardware
HM Handrail mounting plate
(including 2” hardware)
Other Options
KSx
Keyboard Security Code (x
= level of security. See
Security Code Option)
F2 Output is the function of
two inputs: ratio,
differential, average.
SPH Specific pH (TC for NH3 in
condensate)
PA Signal conditioner is
mounted inside the
transmitter enclosure
SC Signal conditioner is
mounted through the side
of the enclosure
ZPR Hazardous area Z-purge
AV Field selectable time
average (2 to 32 seconds)
Typical Example
LXT-230-OR/MA-PM - LXT-230 transmitter
for use with an ORP sensor.
