A-3
Teledyne Analytical Instruments
Portable Oxygen Analyzer
Appendix
Recommended Spare Parts List
(Items with model numbers in parentheses apply to those models only.)
QTY
PART NO.
DESCRIPTION
1
0-55
O-Ring Cell Saver Gasket—Haskel No. 568-022
4
B-73
Battery 1.5 V D-Size Mallory No. MN1300
(320B)
3
B-71
Battery 2.5 V,4.0 amp-hours, NI-CAD
(320BRC/D & P/D)
2
B-71
Battery 2.5 V,4.0 amp-hours, NI-CAD
(320B/RC, P)
1
A-9549
P.C. Board, Amplifier
(320A & B)
1
A-9551
P.C. Board, Amplifier
(320B/RC)
1
A-9736
P.C. Board, Amplifier
(320P)
1
B-23685
I.C. Board, Amplifier
(320BRC/D)
1
C-6689-
Micro-fuel Cell: Customer Must specify the class
Class
Color Code
Ck
A-3
Black
___
A-5
Gray
___
B-1
Tan
___
C-3
Red
___
1
A9340A
Cell Saver Cap with Chain
2
B-60
Battery Holder
(320A & B)
4
B-39
Bumper
1
A-9899
Probe Holder
1
P-150
Span Potentiometer
1
S-894
Range Switch (320A)
1
S-139
Range Switch
(320B, B/RC, P)
1
K-4
Knob
1
H-25
Handle
1
B-30717
Digital Meter Assembly
(320BRC/D & P/D)
1
M-23
Meter
(320A & B)
1
M-53
Meter
(320B/RC)
1
M-61
Meter
(320P)
5
F-6
Fuse 1/4A (0.25A) 100-125V, 3AG Type,Slow Blow
(US Standard)
5
F-7
Fuse 1/8A (0.125A) 200-250V, 3AG Type, Slow Blow
(US Standard)
2
A-6544
Cell Contact Pin
(320P)
2
A-7023
Cell Contact Spring
(320P)
1
B-64442
Pump Assembly (complete)
(320P, P/D)
5
F-1128
Fuse 1/4A (0.25A) 100-125V, 5x20mm Type, Slow Blow
(International)
5
F-1127
Fuse 1/8A (0.125A) 200-250V, 5x20mm Type, Slow Blow
(International)
