CFIP Marathon series
Ver. 1.10, 2014
Microwave Radio System
PORTS
RF Output (to antenna)
1x N-type Female
4x RJ-45 (data trafic, management port) 10/100/1000 Base-T
Marathon II,
Marathon II HP
Marathon II HP
optional features
E1/T1
4x E1 (4x RJ-45)
+8x E1 (8x RJ-45), 12xE1 version only
3
E1 Fractional mode
1x E1 with fractional E1 G.704 support, 1-32 Time Frames switchable
Serial interface port for traffic
+2x DB-25, V.24/V.28 serial version only³
RSSI port for RSL
2mm test jack, output V vs RSL: 0 to 2V vs -120 to -20dBm
Serial port for MNGT configuration
1x DB-9
Alarm
4 digital inputs, 4 relay outputs (26 pin hi-density D-SUB)
EOW port
2x 3.5mm, headset and mic, 64 Kbps
1+1 Protection port
1x RJ-45, 1xPower protection port³
DC power connector
1x 2ESDV-02 with screw locks
MANAGEMENT
Management ports
Ethernet VLAN or Separate Ethernet (RJ45)
SNMP
Yes, SNMP traps, MIB, SNMP v1/v2c
Element Management System
Web based HTTP, Telnet, FTP, Serial ASCII
Performance graphs
Rx level, Tx level, Radial MSE, LDPC decoder stress, System temperature,
Modem temperature, Input voltage, Power consumption, Equalizer graph,
Uptime (counter only)
Ethernet performance
Per port Ethernet counters, Enhanced radio Ethernet statistics
Loopbacks
E1, modem, RF loopback
ENVIRONMENTAL REQUIREMENTS
Stationary use
Climatic Class 3.1E compliant (ETSI ETS 300 019-1-3); weather
protected locations
Temperature range
-5
o
to +55
o
C
MECHANICAL & TECHNICAL DATA
Marathon II
Marathon II HP
Dimensions: HxWxD
88x482x230mm, 1U 19” Rack
88.9x482x230mm, 2U 19” Rack
Weight
3.8kg
5.2kg
DC port
-40.5V to -57V DC (conforms to ETSI EN 300 132-2)
Built-in DC and antenna port surge protection
Conforms to ETSI EN 301 489-1; EN 61000-4-5; IEC 61000-4-5
Max. Power consumption
Up to 30W
Up to 45W
3
Optional
