WEBSHARE 242W
24
3.6.3 CONFIGURATION
When you click this item, you get following sub-items to configure WebShare 242W
Wireless :
• LAN
• WAN
• System
• Firewall
• QoS
• Virtual Server
• Advanced
3.6.3.1 LAN
A Local Area Network (LAN) is a shared communication system to which many computers
are attached and is limited to the immediate area, usually the same building or floor of a
building.
There are 2 items within the LAN section: Ethernet and DHCP Server.
3.6.3.1.1 Ethernet
The router supports two Ethernet IP addresses in the LAN, and two different LAN subnets
through which you can access the Internet at the same time. Users usually only have one
subnet in their LAN, so there is no need to configure a Secondary IP address. The default IP
address for the router is 192.168.1.254.
RIP: RIP v1, RIP v2, RIP v1+v2 and RIP v2 Multicast.
The Subnet mask of the Secondary IP Address depends on the setting of
the Primary IP Address.
