4 American Dryer Corp. 113406-1
SECTION II
SPECIFICATIONS
A. SPECIFICATIONS
Shaded areas are stated in metric equivalents
IMPORTANT: Gas dryers and steam dryers must be provided with a clean, dry, regulated 80 psi +/-
10 psi (5.51 bar +/- 0.68 bar) air supply.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
MAXIMUM CAPACITY (DRY WEIGHT) 170 lb 77.11 kg
TUMBLER DIAMETER 51-1/2” 130.81 cm
TUMBLER DEPTH 42-3/4” 108.59 cm
TUMBLER VOLUME 51.50 cu ft 1.458 cu m
TUMBLER/DRIVE MOTOR 3 hp 2.24 kW
BLOWER/FAN MOTOR 7-1/2 hp 5.59 kW
DOOR OPENING (DIAMETER) 31-3/8” 79.71 cm
DOOR SILL HEIGHT 36-1/2” 92.71 cm
WATER CONNECTION 3/4”-11.5 NH
DRYERS PER 20’/40’ CONTAINER 3 / 7
DRYERS PER 48’/53’ TRUCK 8 / 8
VOLTAGE AVAILABLE 208-575v 3ø 3,4w 50/60 Hz
APPROX. NET WEIGHT 1,848 lb 838.24 kg
APPROX. SHIPPING WEIGHT 2,014 lb 913.54 kg
AIRFLOW 3,700 cfm 104.77 cmm
HEAT INPUT 395,000 B tu/hr 99,538 kcal/hr
EXHAUST CONNECTION (DIAMETER) 12” 30.48 cm
COMPRESSED AIR CONNECTION 1/4” Qui ck C onnecti on
COMPRESSED AIR VOLUME 4.25 cfh 0.12 cmh
INLET PIPE CONNECTION 1-1/2” F.N.P.T.
VOLTAGE AVAILABLE
N / A
APPROX. NET WEIGHT
APPROX. SHIPPING WEIGHT
AIRFLOW
EXHAUST CONNECTION (DIAMETER)
COMPRESSED AIR CONNECTION
COMPRESSED AIR VOLUME
OVEN SIZE
kW Btu/hr kcal/hr
VOLTAGE AVAILABLE
N / A
APPROX. NET WEIGHT
APPROX. SHIPPING WEIGHT
AIRFLOW
STEAM CONSUMPTION
OPERATING STEAM PRESSURE
EXHAUST CONNECTION (DIAMETER)
COMPRESSED AIR CONNECTION
COMPRESSED AIR VOLUME
BOILER HP (NORMAL LOAD)
SUPPLY CONNECTION
RETURN CONNECTION
Gas
Steam
Electric
