PROLiNK Hurricane 5200C/5201 ADSL2+ Modem / Router
User Manual
Page 17 of 59
Fields in this page:
Field Description
VPI Virtual Path Identifier. This is a read-only field and is selected on the Select
column in the Current ATM VC Table.
VCI Virtual Channel Identifier. This is a read-only field and is selected on the
Select column in the Current ATM VC Table. The VCI, together with VPI, is
used to identify the next destination of a cell as it passes through to the ATM
switch.
QoS Quality of Server, a characteristic of data transmission that measures how
accurately and how quickly a message or data is transferred from a source
host to a destination host over a network. The four QoS options are:
− UBR (Unspecified Bit Rate): When UBR is selected, the SCR
and MBS fields are disabled.
− CBR (Constant Bit Rate): When CBR is selected, the SCR
and MBS fields are disabled.
− nrt-VBR (non-real-time Variable Bit Rate): When nrt-VBR is
selected, the SCR and MBS fields are enabled.
− rt-VBR (real-time Variable Bit Rate): When rt-VBR is
selected, the SCR and MBS fields are enabled.
PCR Peak Cell Rate, measured in cells/sec., is the cell rate which the source may
never exceed.
SCR Sustained Cell Rate, measured in cells/sec., is the average cell rate over the
duration of the connection.
MBS Maximum Burst Size, a traffic parameter that specifies the maximum
number of cells that can be transmitted at the peak cell rate.
Function buttons in this page:
Apply Changes
Set new PVC QoS mode for the selected PVC. New parameters will take effect after the
setting is saved into flash memory and the system is rebooted (see section “Admin” for save
details).
Undo
Discard your settings.
