Preventive maintenance – Poweramp RAIL RAMP SPECIALTY 1.1995 User Manual
Page 19
Warning
Arrow on flow control valve
must point away from hoist
cylinder. Improper installa-
tion will allow Railramp to
free fall which could result
in serious injury and/or
property damage.
16
A
B
C
D
E
F
A
Lip Hinge
B
Lip Cylinder Pin
C
Maintenance Locks (2)
D
Rollers
E
Hoist Cylinder Pins (2)
F
Rear Hinge Pins (3)
Figure 15
Preventive Maintenance
